– An oversized power supply using a custom toroidal transformer design
– 6 line-level inputs including a front-mounted 1/8″ mini-jack for personal media players
– Headphone output on 1/4″ TRS jack located on the front panel
– “Class A” output to 5 watts for greater efficiency
– Heat-sink free design incorporating an aluminum chassis for evenly distributed heat dissipation
– RS-232 port for (i) full unsolicited bidirectional feedback and (ii) firmware updates
– IR input for external control
– SimLink™ controller port for 2-way communications with other compatible MOON components
– Rigid chassis construction to minimize the effects of external vibrations
– Optimized selection of very high quality electronic components
– Low operating temperature for an ultra-long life expectancy
Configuration: | Single-ended / 2-channel |
Power Supply Transformer: | 320VA |
Power Supply Capacitance: | 20,000µF |
Class of operation – Amplifier: | A/AB |
Single Ended Inputs (RCA): | 5 pairs |
Mini-jack Input (1/8″): | 1 |
Input Sensitivity: | 370mV – 3.0V RMS |
Input Impedance: | 11,000 Ω |
Preamplifier Output: | 1 pair |
Output Device Types – Amplifier: | Bipolars – 2 per channel |
Output Power @ 8Ω: | 50 Watts per channel |
Output Power @ 4Ω: | 100 Watts per channel |
Output Impedance: | 0.04Ω |
Damping Factor: | > 200 |
Gain: | 37dB |
Dynamic Headroom: | 3dB |
Signal-to-noise Ratio: | 101dB @ full power |
Maximum Output Voltage: | 22 Volts |
Slew Rate: | 20V/µs |
Maximum Current – Peak: | 15 amperes |
Maximum Current – Continuous: | 9 amperes |
Frequency Response : | 10Hz – 100kHz (+0/-3dB) |
Crosstalk @ 1kHz: | -78dB |
IMD: | < 0.05% |
THD (20Hz – 20kHz @ 1 watt): | < 0.015% |
THD (20Hz – 20kHz @ 50 watts): | < 0.02% |
SimLink™ Port: | 1 input + 1 output each on 1/8″ mini-jack |
RS-232 Port: | 9-pin female DB connector |
IR input: | 1/8″ mini-jack |
Remote Control: | CRM-2 Full Function |
Power Consumption @ idle: | 11 Watts |
AC Power Requirements: | 120V / 60Hz 220-240V / 50Hz |
Gewicht: | 10 kg |
Breedte: | 42,9 cm |
Hoogte: | 8,9 cm |
Diepte: | 36,6 cm |
